| Function | Meausre Acceleration |
|---|---|
| Range | 60g |
| Resolution | 5μg |
| Bias K0/k1 | ≤(±5 Mg) |
| Scale Factor Kl | 1.0±0.2 MA/g |
| Product Name | Quartz Accelerometer |
|---|---|
| Material | Stainless Steel |
| Measure Range | 60g |
| Scale Factor | 0.4mA/g |
| Bias | <5mg |
| Function | Acceleration Test |
|---|---|
| Threshold | 30μg |
| Material | Stainless Steel |
| Scale Factor K1 | 1.8～2.4mA/g |
| Working Temp. | -40℃+150℃ |
| Bias K0/k1 | ≤±2mg |
|---|---|
| Repeatability Of Scale Factor Sigma Kl/kl( 1σ，one Month) | ≤15ppm |
| 0g 4 Hours Short Time Stability | ≤10μg |
| Bandwidth | 800~2500Hz |
| Threshold /Resolution | 1μg |
| Function | Conponents In INS |
|---|---|
| Range | 60g |
| Resolution | 5μg |
| Power | ±12~±15V |
| Size | Ф18.2X23mm |
| Range | ±70g |
|---|---|
| Resolution | 5μg |
| Bias K0/k1 | ≤(±1 Mg) |
| Scale Factor Kl | 0.8~1.5 MA/g |
| Bias Drift Sigma K0( 1σ，one Month) | ≤20 μg |
| Product Name | Low Cost Quartz Acelerometer |
|---|---|
| Scale Factor K1 | 0.8~1.5 MA/g |
| Working Temp. | -55～+85℃ |
| Bias K0/K1 | ≤±5 Mg |
| Power Supply | ±12~±15V |
| Function | Vibration Test |
|---|---|
| Operating Voltage | ±（12～18）VDC |
| Insulation Resistance | 50MΩ，@50VDC |
| Power Consumption | ≤480mw@±15VDC |
| Current Consumption | ≤16mA@±15VDC |
| Product Name | Quartz Flexure Accelerometer |
|---|---|
| Application | Vibration Measure In IMU, INS |
| 0g 4hours Short-term Stability | ≤30 μg |
| Bias Thermal Coefficient | ≤±80 μg /℃ |
| Scale Factor Thermal Coefficient | ≤±100 Ppm /℃80 |
| Name | Quartz Flexure Accelerometer |
|---|---|
| Range | +/-30g |
| Material | Stainless Steel |
| Bias K0/K1 | ±30g |
| Thermal Coefficient | ＜50µg/℃ |
